Firestone W013587304 High Strength Airstroke Actuator/Airmount Isolator

Product Description

Firestone W013587304 is a high strength airstroke actuator and airmount isolator. This product is designed for various industrial applications requiring linear or angular motion. The actuator features a compact profile which is beneficial compared to traditional air cylinders.

• Designed for industrial use in reducing vibrations.
• Effective for use in press machines and conveyors.
• Temperature range from -35 °F to 135 °F.

Product Highlights

Firestone air springs provide effective motion and vibration control, optimizing performance across devices.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013587304

Technical Specifications

• Pressure (Max): 100 psi
• Style No.: 321
• Bolt Circle Diameter: 23 1/2 inches
• Stroke Length (Max): 14.200 inches
• Air Inlet Type: NPT
• Bumpers: Without bumpers
• Force at 1 inch Stroke: 43,300 lbf
• Force at 3 inch Stroke: 41,200 lbf
• Bellows Type: Triple convolution, high strength
• Number of Bolts: 32
• Weight: 54.5 lb
