Firestone W013587273 Double Convolute Airstroke Actuator/Airmount Isolator

Product Description

Firestone W013587273 is a double convolute airstroke actuator and airmount isolator. This air spring acts as both an actuator and vibration isolator, providing linear or angular motion in a compact design. Its flexible structure serves various industrial applications, including pressing, conveying, lifting, and packaging. As a vibration isolator, it effectively diminishes vibration impacts in machines.

• Two-ply, fabric-reinforced rubber
• Operates effectively under extreme temperatures
• Durable rolled plate assembly with blind nuts

Product Highlights

The Firestone air spring is engineered to meet the demands of industrial use with its durable construction and effective vibration dampening properties.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013587273

Technical Specifications

• Pressure Max: 100 psi
• Temperature Range Min: -35 °F
• Style No.: 203
• Air Inlet Type: NPT
• Compressed Height: 3.3 in
• Stroke Length Max: 7.200 in
• Force @ 1 in Stroke: 21400 lbf
• Force @ 3 in Stroke: 19200 lbf
