Firestone W013583400 Double Convolute Airstroke Actuator/Airmount Isolator

Product Description

The Firestone W013583400 is a double convolute airstroke actuator and airmount isolator. This air spring serves as an industrial actuator and a vibration isolator. It allows for linear and angular motion with a low-profile design, suitable for various machinery applications such as pressing, lifting, and packaging.

• Two-ply, fabric-reinforced rubber
• Flexible media for diverse applications
• Effective vibration dampening

Product Highlights

This air spring is designed for various industrial uses. It enhances machine performance while minimizing vibration impacts.

Product Information

Standard Information

• Brand: Firestone
• Part Number: W013583400

Technical Specifications

• Compressed Height: 2.8 inches
• Stroke Length Maximum: 4.700 inches
• Temperature Range Minimum: -35 °F
• Temperature Range Maximum: 135 °F
• Pressure Maximum: 100 psi
• Force at 1 inch Stroke: 2888 lbf
• Force at 3 inch Stroke: 2125 lbf
• End Closure: Type 1 Bead Plate
• Air Inlet Type: NPT
• Air Inlet: 1/4 inch
