Firestone W013580812 Airstroke Actuator/Airmount Isolator Bellows

Product Description

The Firestone W013580812 is an airstroke actuator and airmount isolator bellows designed for industrial use. This component provides effective linear and angular motion with a low profile compared to traditional air cylinders. The flexible features of this air spring make it suitable for various applications, including pressing, conveying, lifting, and packaging. Additionally, it serves as a vibration isolator to minimize the harmful impact of vibration on machinery.

• Double convolution design for durability
• High-temperature bellows
• Style number twenty-two

Product Highlights

Ideal for industrial settings, this product enhances efficiency and reduces wear on machines through effective vibration isolation.

Product Information

Standard Information

• Brand: Firestone
• Part Number: 101482760

Technical Specifications

• Force at Maximum Stroke (eighty psi): 3700 lbf
• Stroke Length (Maximum): 7.100 inches
• Pressure: 100 psi
• Force at three inch Stroke: 6470 lbf
• Minimum Height: 3 inches
• Force at one inch Stroke: 7180 lbf
• Style Number: 22
• Bellows Type: Double convolution
• Bellows Duty: High-temperature
• Weight: 8.6 lb
• EAN or UPC: 767555001875
