Fire Protection Prod 06-810-00 Globe Valve Soft Seat 2 IN

Product Description

The FIRE PROTECTION PROD 06-810-00 globe valve is designed for fire sprinkler systems, typically used in trim or drain applications. This valve is UL/ULC listed to 300 PSI and features a full floating seat holder for reduced seat wear. It is suitable for both regular (175 PSI) and high pressure (300 PSI) sprinkler systems.

• TrimFit® bronze globe valves are precision cast and machined.
• Features a full floating seat holder for reduced seat wear.
• PTFE seat for longer seat life and reduced maintenance.

Product Highlights

This 2 IN globe valve starts, stops, and throttles water flow in water-based fire protection systems. It has a bronze body and FNPT connection.

Product Information

Standard Information

• Brand: FIRE PROTECTION PROD
• Manufacturer Part Number: 06-810-00

Technical Specifications

• Sub Brand: TrimFit®
• Item Name: Globe Valve With Soft Seat
• Nominal Size: 2 IN
• Connection Type: FNPT
• Pressure Rating: 300 PSI
• Body Material: Bronze
• Operator Type: Handwheel
• Handle Material: Cast Iron
• Seat Material: PTFE
• Material Standard: Handle: JIS FC 20
• Finish/Color: Red Handwheel
• Industry Standards: C/US UL Listed 2R97
• Lead Free: No
• Manufacturer Part Number: 06-810-00
• Manufacturer: FPPI™
• Valve Type: Globe Valve
• Number of Connections: 2 Connections
• UL Listed: Yes
• FM Approved: No
• Rated Working Water Pressure: 175 and 300 psi
• Water Oil Gas Pressure (WOG): 300 WOG
