Fire Protection Prod 06-600-00 1/4 inches fnpt 3-way gauge valve (brass)

Product Description

The FIRE PROTECTION PROD 06-600-00 three-way valve is manufactured from high-quality brass alloy and is UL/ULc Listed. This 1/4" valve streamlines air and water pressure monitoring for water-based fire protection systems. It is suitable for pressure testing and monitoring in dry-pipe and wet-pipe fire sprinkler systems.

• 1/4" size
• Constructed from brass
• Rated to 300 PSI

Product Highlights

This brass three-way valve is ideal for monitoring air and water pressure in fire protection systems.

Product Information

Standard Information

• Brand: FIRE PROTECTION PROD
• Manufacturer Part Number: 06-600-00

Technical Specifications

• Size: 1/4"
• Material: Brass
• Approvals: UL
• Max Pressure (PSI): 300
• Connection Type: FNPT
• Manufacturer Part Number: 06-600-00
• Manufacturer: FPPI™
• Valve Type: Three Way Valve
• Number of Connections: 3 Connections
• Body Material: Brass
• Size Detail: 1/4 in. IPS x 1/4 in. IPS x 1/4 in. IPS
• UL Listed: Yes
• FM Approved: No
• Water Oil Gas Pressure (WOG): 400 WOG
• Finish: Brass
• Length: 1.61 in. (40.89 mm)
• Width: 1.04 in. (26.42 mm)
• Height: 1.31 in. (33.27 mm)
