Fibre-metal 69029109142 45 Degree Elbow 1-1/4 in 3000lb Sw

Product Description

The FIBRE-METAL 69029109142 is a 45-degree forged steel socket weld elbow fitting rated at 3000 lb, sized at 1-1/4 inches. This full-size (FS) fitting is manufactured to ASTM A105 carbon steel specifications, making it suitable for high-pressure piping systems. It accepts pipe into a recessed socket end and is welded in place, providing a strong, leak-resistant connection. Licensed plumbers and pipefitters install this fitting in process, industrial, and commercial mechanical piping systems where directional changes and pressure integrity are required.

This 45-degree elbow is used in socket weld piping assemblies operating at elevated pressures. The 3000 lb pressure class fits standard schedule 80 and heavier pipe in steam, hydraulic, gas, and liquid service applications. It is a common component in industrial process lines, commercial HVAC piping, and mechanical room installations where a 45-degree change of direction is needed in a 1-1/4 inch line.

Key Features

• 45-degree angle provides a gradual directional change with lower flow resistance than a 90-degree elbow
• Socket weld end connection allows pipe insertion before fillet welding for a secure, high-pressure joint
• 3000 lb pressure class rated for demanding high-pressure service
• ASTM A105 forged carbon steel construction for strength and durability in industrial service
• Full-size (FS) bore maintains consistent flow path through the fitting

Compatibility

Designed as an OEM-style forged steel socket weld fitting for use in 1-1/4 inch Class 3000 piping systems conforming to ASTM A105 material requirements.

Installation Notes

Installation must be performed by a licensed pipefitter or plumber in accordance with applicable codes such as ASME B31.1 or B31.3 for pressure piping. Shut down and depressurize the piping system completely before cutting in or replacing any fitting. Socket weld connections require proper pipe insertion depth and a fillet weld applied per applicable welding procedure specifications. Do not use this fitting in applications exceeding its rated pressure class or with incompatible pipe materials.

Technical Specifications

• Size: 1-1/4 inches
• Pressure Class: 3000 lb
• End Connection: Socket Weld
• Fitting Angle: 45 degrees
• Material: Forged Carbon Steel, ASTM A105
• Pattern: Full Size (FS)

Standard Information

• Brand: FIBRE-METAL
• Manufacturer Part Number: 69029109142
