FERRAZ SHAWMUT 20608 Fuse Block 250V 3-Pole Class H/K

Product Description

The FERRAZ SHAWMUT 20608 is a three-pole fuse block designed for Class H/K fuses. This fuse block operates effectively in both AC and DC circuits with a rated voltage of 250 volts.

• Accommodates Class H/K fuses.
• Features clip-in fuse installation for ease of use.
• ROHS compliant for environmentally safe usage.

Product Highlights

This fuse block supports a maximum amperage rating of sixty amps and is constructed from glass-filled polycarbonate, ensuring durability and reliability in various applications.

Product Information

Standard Information

• Brand: FERRAZ SHAWMUT
• MPN: 20608

Technical Specifications

• Voltage Rating: 250 V
• Poles: 3
• Phase: 3
• Amperage Rating: 60 A
• Fuse Class: Class H/K
• Short Circuit Current Rating (SCCR): 50 kA
• Fuse Installation Method: Clip-in
• Mounting Type: Direct screw mount
• Body/Insulating Material: Glass filled polycarbonate
• Frequency: 50/60 Hz
• Torque Rating: 45 lb-in
• Product Width: 4.08 inches
• Product Length: 4.75 inches
• Product Height: 2.12 inches
• Product Weight: 0.65 lb
• ROHS Compliant: Yes
