Fenwal 35-630501-103 Intermittent Pilot Ignition Control 24V (15 sec Prepurge/30 sec TFI) 35-630501-103

Product Description

The Fenwal 35-630501-103 is a robust intermittent pilot ignition control that operates with a 24V system, featuring a 15-second prepurge and a 30-second trial for ignition (TFI). Engineered for precise temperature control, this electronic module is ideal for a variety of HVAC and industrial settings.

• Microprocessor-based design ensures accurate timings and sequences.
• DETECT-A-FLAME technology provides reliable flame sensing.
• Easy to install with standard 4-inch junction box mounting.

Product Highlights

This control unit improves system reliability through advanced diagnostics and a smart LED interface that simplifies troubleshooting. Its safe start function and customizable timings enhance functional adaptability to different environments.

Product Information

Standard Information

• Brand: Fenwal
• MPN: 35-630501-103
• Voltage: 24 Volts
• Gas Type: Compatible with Natural, LP, and Manufactured Gas

Technical Specifications

• Ignition Type: Intermittent Pilot
• Temperature Range (F): -40F to 176F
• Flame Sensing: Minimum 0.7
• Dimensions: Weight: 0.9 lbs, Depth: 6.75 inches, Width: 4.4 inches, Height: 3.35 inches
