Federal Signal VALS-024R Visalert Strobe 24 VDC (3.95 x 3.94 x 1.6 in)

Product Description

Federal Signal VALS-024R is a Visalert three-dimensional triangular strobe warning light that operates at 24 VDC. The unit uses a linear xenon strobe tube with circuitry contained in the lens, draws 0.08 A, and provides a high peak candela output for visual warning in industrial indoor and outdoor applications. The polycarbonate housing and NEMA 3R/IP44 enclosure support surface mounting and compatibility with Federal Signal 350 Vibratone horn and 50GC SelecTone speaker.

• Operates at 24 VDC, 0.08 A with linear xenon strobe tube and approximately 4,000 hour lamp life
• High output visual warning: 108,000 peak candela and 80 flashes per minute
• Polycarbonate housing, conformal coated PCB, NEMA 3R/IP44 enclosure; surface mount compatible with Model 350 and 50GC devices

Product Highlights

Visalert triangular strobe, 24 VDC, 108,000 cd peak, 4,000 hr lamp life, NEMA 3R/IP44, surface mount

Product Information

Standard Information

• Brand: FEDERAL SIGNAL
• Manufacturer Part Number: VALS-024R
• Country of Origin: United States

Technical Specifications

• Brand: Federal Signal
• Manufacturer Part Number: VALS-024R
• Series: VALS
• Sub Brand: Visalert
• Input Voltage: 24 VDC
• Operating Current: 0.08 A (80 mA)
• Light Source: Linear xenon strobe tube
• Lamp Life: 4000 hr
• Flash Rate: 80 flashes per minute
• Peak Candela: 108000 cd
• Mounting Type: Surface (flush or surface mount on compatible devices)
• Mounting Compatibility: Compatible with Federal Signal Model 350 Vibratone horn and Model 50GC SelecTone speaker/amplifier
• Dimensions: 3.95 in H x 3.94 in W x 1.60 in D
• Weight: 0.1 lb
• Housing Material: Polycarbonate
• PCB Protection: Conformal coated PCB
• Enclosure Rating: NEMA 3R / IP44
• Operating Temperature: -31 to 150 deg F
• Certifications: UL Listed, CSA Certified
• Application: Indoor and outdoor industrial visual warning
• Shape: Triangular
