FASTENERS WEDGE-ANCR-3/8X5 Wedge Anchor

Product Description

The FASTENERS WEDGE-ANCR-3/8X5 is a wedge anchor made for use with concrete and masonry. This anchor is made of carbon steel with a zinc plating, which makes it strong and durable. It is designed to handle both static and seismic loads. Each clip segment has dual undercutting embossments. This feature allows the anchor to expand if a crack is detected in the material. The top is chamfered to reduce the risk of mushrooming during installation. It can be used in positions like horizontal, vertical, or overhead.

• Made from carbon steel for maximum strength
• Features dual undercutting embossments for improved load capacity
• Chamfered top prevents mushrooming during installation

Product Highlights

This anchor is ideal for various installation types and environments.

Product Information

Standard Information

• Brand: FASTENERS
• MPN: WEDGE-ANCR-3/8X5

Technical Specifications

• Diameter: 3/8
• Length: 5
• Material: Carbon Steel
• Finish: Zinc Plated
• Drill Bit Size: 3/8
• Thread Length: 3-9/16
• Nut Material: Carbon Steel ASTM A563, Grade A
• Washer Material: Carbon Steel ASTM F844
• Clip Material: Carbon Steel ASTM A568
