Fasteners WEDGE-ANCR-1/2X41/4

Product Description

The Fasteners WEDGE-ANCR-1/2X41/4 is a zinc-plated wedge anchor designed for fastening items securely to concrete surfaces. It has a diameter of one-half inches and a length of four and one-quarter inches. This anchor is suitable for dry indoor environments and comes packaged with matching zinc-plated nuts and washers, making it an ideal choice for various fastening applications.

• Designed for concrete fastening.
• Zinc-plated for durability.
• Includes nuts and washers.

Product Highlights

The WEDGE-ANCR-1/2X41/4 is engineered to provide strong and reliable support for fixtures mounted on concrete, ensuring a secure hold.

Product Information

Standard Information

• Type: Male
• Environment: Dry

Technical Specifications

• Bit Size: 1/2
• Minimum Embedment: 2-1/4
• Thread Length: 2-3/4
• Thread Type: 1/2 - 13
• 2000 PSI Concrete - Pull-Out (lbs): 2999
• 2000 PSI Concrete - Shear (lbs): 5564
• Diameter: 1/2
• Length: 4-1/4
• Material: Carbon Steel Zinc Plated
• Box Quantity: 25
• Minimum Spacing: 5
• Minimum Edge Distance: 2-1/2
• Maximum Fixture Thickness: 1-1/2
• Minimum Fixture Hole Diameter (In Place): 5/8
• Minimum Fixture Hole Diameter (Hole Spotted): 1/2
• Maximum Torque: 50 - 60 ft./lbs.
• Wrench Size For Nut: 3/4
• Hole Size: 1/2
