FASTENERS HH-CAP-SCR-1/4-20X1-G-5

Product Description

The FASTENERS HH-CAP-SCR-1/4-20X1-G-5 is a reliable hex head cap screw designed for easy assembly into a tapped hole. This screw meets the SAE specifications and features a specially designed washer face under the head to ensure a secure fit. The chamfered point facilitates insertion into the material.

• Designed for easy assembly into a tapped hole.
• Meets SAE specifications with a washer face under the head and a chamfered point.
• Zinc plating retards corrosion in normal atmospheres.

Product Highlights

The FASTENERS HH-CAP-SCR-1/4-20X1-G-5 is Grade 5, making it suitable for various manufacturing assembly applications. It has a tensile strength of 120,000 psi minimum, providing durability and strength.

Product Information

Standard Information

• Thread Size: 1/4-20
• Length: 1 inch

Technical Specifications

• Grade: 5
• Finish: Zinc
• Thread Type: Coarse
• Thread Style: Full Thread
• Standards: ASME B18.2.1, SAE J429, ASTM F1941/F1941M
• Wrench Size: 7/16 inch
• Tensile Strength: 120,000 psi
• Head Height: 0.150 - 0.163 inches
• Head Width: 0.428 - 0.438 inches
