Fasco RS1051A Industrial Motor, 1/2hp CapStart 115/230v ODP ResBase BallBr

Product Description

The FASCO RS1051A is an industrial motor with 1/2hp CapStart, designed for 115/230V operation. It features an Open Drip Proof (ODP) enclosure, Resilient Base mounting, and Ball Bearing construction. Suitable for HVAC applications, this motor ensures reliable performance in various industrial settings.

• Automatic reset thermal protector prevents overheating.
• Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.

Product Highlights

This motor is designed for industrial applications requiring a robust and reliable power source.

Product Information

Standard Information

• Brand: FASCO
• Manufacturer Part Number: RS1051A
• Country of Origin: Mexico

Technical Specifications

• Application: HVAC
• Phase: 1
• Output HP: 1/2 Hp
• Output KW: 0.37 kW
• Voltage: 115/230 V
• Speed: 1725 rpm
• Service Factor: 1.0
• Frame: 56
• Thermal Protection: Automatic
• Ambient Temperature: 40 °C
• Frequency: 60 Hz
• Current: 8.6/4.3 A
• Duty: Continuous
• Insulation Class: B
• CSA: Y
• Number of Speeds: 1
• Electrical Type: Capacitor Start Induction Run
• Starting Method: Across The Line
• Poles: 4
• Rotation: Reversible
• Mounting: Resilient Base
• Drive End Bearing: Ball
• Opp Drive End Bearing: Ball
• Frame Material: Rolled Steel
• Shaft Type: Keyed
• Overall Length: 10.28 in
• Frame Length: 5.44 in
• Shaft Diameter: 0.625 in
• Shaft Extension: 2 in
