Fasco G3D002 Direct Drive Motor 1/4 HP 1075 RPM

Product Description

The Fasco G3D002 Direct Drive Motor is a reliable motor designed for HVAC applications. With an electrical type of PSC, it operates at 1/4 HP and 1075 RPM. The motor has a 48Z frame and a diameter of 5.6 inches. It features a single phase and a voltage of 277/230, making it suitable for various systems. This motor is constructed with rolled steel and has a reverse rotation. It mounts using a belly band and has a single shaft type.

• Direct Drive Motor
• 1/4 HP, 1075 RPM
• Single Phase, 277/230 Voltage

Product Highlights

This Fasco motor is ideal for HVAC applications, offering reliable performance with a PSC electrical type and a robust rolled steel construction. It features multi-speed operation and reverse rotation for versatility in various setups.

Product Information

Standard Information

• Brand: Fasco
• MPN: G3D002

Technical Specifications

• Electrical Type: PSC
• Horsepower: 1/4
• RPM: 1075
• Frame: 48Z
• Diameter: 5.6 inches
• Enclosure: OAO
• Phase: Single
• Voltage: 277/230
• Rotation: REV
• Material: Rolled Steel
• Mounting: Belly Band
• Amperage: 1.1
• Shaft Type: Single
