Fasco G3204HS Condenser Fan Motor PSC 1/4 HP 825 RPM 5.6 Diameter 48Z TEAO Single Phase

Product Description

The Fasco G3204HS Condenser Fan Motor is a reliable and efficient solution for HVAC systems. This motor features a Permanent Split Capacitor (PSC) design and offers 1/4 horsepower. It operates at 825 RPM and includes a 5.6 inch diameter. The frame is 48Z, housed in a Totally Enclosed Air Over (TEAO) enclosure, making it suitable for single-phase applications.

• PSC type condenser fan motor
• 1/4 horsepower with 825 RPM
• 48Z frame and TEAO enclosure

Product Highlights

This Fasco motor is designed for use in HVAC condenser fans. Its rolled steel construction and automatic overload protection ensure long-lasting performance. The motor supports a voltage range of 208-230V with a single shaft type and belly band mounting.

Product Information

Standard Information

• Brand: Fasco
• MPN: G3204HS

Technical Specifications

• Electrical Type: PSC
• Horsepower: 1/4 HP
• RPM: 825
• Frame: 48Z
• Diameter: 5.6 inches
• Enclosure: TEAO
• Phase: Single
• Voltage: 208-230 V
• Rotation: Reverse
• Overload Protection: Auto
• Material: Rolled Steel
• Mounting Type: Belly Band
• Amperage: 1.3 A
• Shaft Type: Single
