Product Description
The Fasco EC-4W115 is a refrigeration motor suitable for various industrial and commercial applications. This motor operates at one over one hundred eighty-five horsepower and is designed to work with refrigeration systems, condensing units, and evaporating units. It supports food and beverage coolers, bottle coolers, and walk-in or reach-in coolers. The motor is capable of continuous operation and is suitable in environments where air cooling is necessary.
- Powerful motor rated at 1/185 horsepower.
- Operates on 115V with an amperage of .36A.
- Designed for refrigeration applications including freezers and coolers.
Product Highlights
This motor is thermally protected, uses Class B insulation, and features an all-angle sleeve bearing. With an operating temperature range from forty degrees below zero to one hundred four degrees Fahrenheit, it is built to handle diverse environments.
Product Information
Standard Information
-
Brand: Fasco
-
MPN: EC-4W115
Technical Specifications
-
Motor Type: Shaded Pole
-
Diameter: 6 inches
-
Power: 1/185 hp
-
Voltage: 115V
-
Amperage: 0.36A
-
RPM Range: 1201 to 1800
-
Enclosure: Totally Enclosed Air Over (TEAO)
-
Mount: Stud
-
Phase: Single
-
OEM: Yes
-
Rotation: CCW
-
RPM: 1550
-
Speed: 1
-
Series-Brand: ELCO
-
Vendor: Fasco
