Fasco D792 Condenser Fan Motor 1/4 HP 825 RPM 208-230V

Product Description

The Fasco D792 is a condenser fan motor featuring a 5.6-inch frame diameter and a power rating of one-fourth horsepower. This motor operates at eight hundred twenty-five revolutions per minute and is designed for voltages of two hundred eight to two hundred thirty volts. It has a single phase, permanent split capacitor design, making it suitable for various cooling applications.

• Single-phase permanent split capacitor
• Operates at 825 RPM with 1.8 amps
• Open ventilated design suitable for various installations

Product Highlights

This motor is thermally protected and features ball bearings for smooth operation. It is designed to be mounted in multiple positions with extended studs for easy installation. With a durable rolled steel construction, this motor ensures longevity and reliability in harsh conditions.

Product Information

Standard Information

• Brand: Fasco
• MPN: D792

Technical Specifications

• Diameter: 5.6 inches
• Frame: 48Z
• Voltage: 208-230 V
• Amperage: 1.8 A
• Power: 1/4 HP
• RPM: 825
• Mounting Type: Extended Studs
• Shaft Type: Double Flat
• Weight: 4 lbs
