Fasco D1061 Shaded Pole Motor 1/20-1/30-1/60 HP 115 Volts

Product Description

The Fasco D1061 is a shaded pole motor with a diameter of four point four inches. It operates at one hundred fifteen volts and delivers speeds of one thousand five hundred RPM. This motor provides one twentieth, one thirtieth, and one sixtieth horsepower and features a counter-clockwise rotation along with a sleeve bearing. It serves general purpose applications needing dependable performance.

• Four point four inch diameter
• Shaded pole motor design
• Multiple horsepower options

Product Highlights

This motor is suitable for various applications across different environments, ensuring reliability and efficiency. Ideal for use in fans, blowers, and other equipment requiring consistent motor performance.

Product Information

Standard Information

• Brand: Fasco
• Model: D1061

Technical Specifications

• Speed: 1500 RPM
• Voltage: 115 Volts
• Horsepower: 0.05 HP
• Mounting: Extended Stud
• Frequency Rating: 60 Hertz
• Service Factor: 1
• Enclosure Type: Open Ventilation
• Rotation: CCW
• Shaft Diameter: 1/2 inch
• Shaft Length: 2 3/4 inches
• Max. Ambient Temp.: 40 Degrees C
• Overall Length: 6 7/8 inches
• Poles: 4/6
• Amperage: 2.0-1.7-1.4
• Shaft Type: Flat
