Fasco A174 1-Speed 2350 RPM 1/100 HP Intercity Draft Inducer Motor 115V

Product Description

The Fasco A174 is a 1-speed intercity draft inducer motor designed for HVAC systems. This motor operates at a speed of two thousand three hundred fifty RPM and has a power output of one hundredth of a horsepower. It works with a voltage of one hundred fifteen volts.

• Replaces ICP part numbers 7021-9188 and 1010239
• Ideal for use in various residential HVAC applications
• Features sleeve bearings for smooth operation

Product Highlights

This draft inducer motor is a direct replacement for several ICP models, making it a reliable choice for maintenance and repairs.

Product Information

Standard Information

• Brand: Fasco
• MPN: A174

Technical Specifications

• RPM: 2350
• Horse Power: 1/100
• Voltage: 115V
• Amperage: 0.8
• Hertz: 60
• Phase: 1
• Speeds: 1
• Bearings: Sleeve
• Rotation: CW
• Enclosure Type: Open
• Insulation Class: B
• Max Ambient Temperature: 104°F
• Shipping Dimensions: 11 inches (Depth) x 11 inches (Width) x 10.95 inches (Height)
• Approvals: CSA, UL
