Fasco 116744.00 116744 General Purpose Motor, 2 HP, 1745 RPM, 230/460 V

Specifications:

Output HP: 2 Hp
Output KW: 1.5 k
W
Frequency: 60 Hz
Voltage: 230/460 V
Current: 5.8/2.9 A
Speed: 1745 rpm
Service Factor: 1.25
Phase: 3
Efficiency: 86.5 %
Power Factor: 75.6
Duty: Continuous
Insulation Class: F
Frame: 56C
Enclosure: Totally Enclosed Fan Cooled
Thermal Protection: Thermostat
Ambient Temperature: 40 C
Drive End Bearing Size: 6203
Opp Drive End Bearing Size: 6203
UL: Recognized
CSA: Y
CE: Y
Number of Speeds: 1
