Falk Corp. 2080FC3B-130.4 UltraMax Concentric Gear Reducer

Product Description

The Falk Corp. 2080FC3B-130.4 is a reliable UltraMax Concentric Gear Reducer designed for efficient power transmission. This gear reducer features an input shaft size of two inches and an output shaft size of three and a half inches, offering a reduction ratio of 130.4 to one.

• 2 in Input Shaft
• 3 1/2 in Output Shaft
• 130.4:1 Reduction Ratio

Product Highlights

High-quality gear reducer for various applications.

Product Information

Standard Information

• Brand: Falk Corp.
• Part #: 101650270

Technical Specifications

• Shaft Arrangement: Concentric Gear Drive
• Mounting: Horizontal
• Output (Shaft or Bore) Size: 3 1/2 in
• Housing Material: Fabricated Steel
• Reduction Type: Triple
• Series: 2000
• Box Length: 15.8 in
• Bolt Centers w/ Std. Base Kit (in): 6.1 x 13.2
• Seal Material: Nitrile
• Ratio: 130.4:1
• Keyway: 7/8 x 7/8 x 6 1/2
• Unit Size: 2080
• Box Width: 23 in
• Input (Shaft or Bore) Size: 2 in
• Base to Shaft Center Height w/Std. Base Kit: 12.78 in
• Box Height: 18.98 in
• Model: B
• Weight: 680.0 LB
• EAN or UPC: 782934639067
