Falk 2120FC2B-31.89 UltraMax Concentric Gear Reducer

Product Description

The Falk brand 2120FC2B-31.89 is an UltraMax Concentric Gear Reducer designed for efficiency in various industrial applications. This gear reducer features a robust construction and a high ratio for effective torque conversion.

• Input Shaft Size: 3 1/4 inches
• Output Shaft Size: 5 1/2 inches
• Reduction Ratio: 31.89:1

Product Highlights

This reducer provides reliable performance and is suitable for various gear drive setups.

Product Information

Standard Information

• Brand: Falk Corp.
• Part Number: 101651532

Technical Specifications

• Model: B
• Ratio: 31.89:1
• Unit Size: 2120
• Input (Shaft or Bore) Size: 3 1/4 inches
• Output (Shaft or Bore) Size: 5 1/2 inches
• Weight: 2210.0 lbs
• Mounting: Horizontal
• Box Height: 32 1/2 inches
• Box Width: 32.48 inches
• Box Length: 23.6 inches
• Housing Material: Fabricated Steel
• Seal Material: Nitrile
• Reduction Type: Double
• Shaft Arrangement: Concentric Gear Drive
• Keyway: 1 1/4 x 1 1/4 x 9
• Bolt Centers with Std. Base Kit: 6.1 x 13.2 inches
• Base to Shaft Center Height with Std. Base Kit: 21.9 inches
• EAN or UPC: 782934640919
