Falk 203UCBN2A32AB Ultramite Inline Concentric Helical Reducer

Product Description

The Falk 203UCBN2A32AB is an Ultramite Inline Concentric Helical Reducer designed for efficient power transmission in various applications. This reducer features a thirty-two to one ratio, making it suitable for a range of mechanical needs. The unit includes a one-inch output shaft, which is ideal for use in industrial settings.

• Reduction Type: Double
• Output Shaft Size: 1 inch
• Ratio: 32:1

Product Highlights

This Ultramite reducer is constructed to deliver reliability and durability, making it an essential component for mechanical systems. Its base mount design ensures easy installation and stability during operation.

Product Information

Standard Information

• Brand: Falk Corp.
• Part #: 104084995

Technical Specifications

• Model: A
• Frame: 143TC/145TC
• Box Width: 5.71 inches
• Box Height: 7.09 inches
• Box Length: 10.61 inches
• Weight: 48.6 LB
• Mounting: Base Mount
• Hole Diameter: 0.39 inches
• Keyway: 1/4 x 1/4 x 1 9/16
• Bolt Centers w/ Std. Base Kit: 5.12 x 4.33 inches
• Base to Shaft Center Height w/Std. Base Kit: 3.54 inches
• EAN or UPC: 782934316326
