Falk 1060T20CPLGRB T-Tapered Steelflex Coupling

Product Description

The Falk 1060T20CPLGRB is a T-Tapered Steelflex Coupling designed for various applications requiring high strength and flexibility. This coupling features a vertical cover, ideal for higher running speeds. It has a replace-in-place design that eliminates the need for realignment, enhancing operational efficiency. The high strength alloy steel grids are quenched and tempered to achieve spring hardness, providing durable and reliable performance.

• Vertical cover enables higher running speeds
• Replace-in-place design for easy installation
• High strength steel grids for increased durability

Product Highlights

The coupling is designed to torsionally deflect when subjected to normal shock or vibratory loads, which allows for flexibility in accommodating changing load conditions.

Product Information

Standard Information

• Brand: Falk Corp.
• Part #: 102215492

Technical Specifications

• Overall Length: 5.125 inches
• Outside Diameter: 6.375 inches
• Torque Rating [Max]: 5500 in lb
• Bore (Hub1) [Max]: 2 1/8 inches
• Bore (Hub2) [Max]: 2 1/8 inches
• Coupling Size: 1060T
• Weight: 26.26 LB
• EAN or UPC: 782934009914
