Fafnir RSAO23/16 Heavy Duty Pillow Block Ball Bearing 2.1881 inch Bore

Product Description

The Fafnir RSAO23/16 is a heavy-duty pillow block ball bearing designed to offer reliable performance in demanding applications. This unit integrates the bearing, housing, seal, and locking system into one device, simplifying installation and maintenance. Built for longevity, it is suitable for a variety of sectors, including agricultural, food processing, fans, blowers, and conveyors.

• Wide inner ring ball bearing for enhanced stability
• Pre-lubricated and ready for use; includes a grease fitting for re-lubrication
• Eccentric self-locking collar to secure the assembly

Product Highlights

The RSAO23/16 pillow block bearing ensures reduced downtime with advanced technology and robust construction.

Product Information

Standard Information

• Brand: Fafnir
• Manufacturer: Timken

Technical Specifications

• Type: Heavy Duty
• Bore Diameter: 2.1881 inches
• Overall Length: 12.625 inches
• Overall Width: 3.529 inches
• Overall Height: 1.438 inches
• Base Width: 3.5 inches
• Dynamic Load Capacity: 16100 lbs
• Static Load Capacity: 10000 lbs
• Maximum Speed: 2400 rpm
• Temperature Rating: 250 degrees F
• Mounting Type: Two-Bolt Base
• Locking Device: Eccentric Self-Locking Collar
• Seal Type: Contact
• Expansion Type: Non-Expansion (Fixed)
• Base to Bore Centerline: 3.75 inches
• Bolt Center-to-Center Length: 10.25 inches
• Finish: Uncoated
• Series: RSAO Series
• Application: Agricultural, Food Processing, Fans, Blowers and Conveyors Applications
