Fafnir G1100KPPB3 Ball Bearing Insert 1.375 in 52 mm 15 mm

Product Description

The Fafnir G1100KPPB3 is a ball bearing insert designed for reliable performance in demanding applications. This bearing insert features a one-inch bore and is made from durable steel. It comes with a double-sealed design that protects against contaminants, ensuring longevity in various conditions.

• Manufactured from steel for strength
• Includes eccentric locking collar for secure mounting
• Relubricatable for prolonged service

Product Highlights

The G1100KPPB3 is ideal for use in environments where contamination is a concern. It provides excellent sealing capabilities and can be easily integrated into standard housings.

Product Information

Standard Information

• Brand: Fafnir
• MPN: G1100KPPB3

Technical Specifications

• Outer Ring Size: 205
• Length Through Bore: 1.375 in
• Bearing Type: Ball Bearing
• Bore Type: Round Bore
• Overall Width: 1.375 in
• Lubrication: Relubricatable
• Duty: Standard-Duty
• Seal Type: Contact Seals
• Locking Device: Eccentric Locking Collar
• O.D.: 52 mm
• Enclosure: Double Sealed
• Dynamic Load Rating: 3450 lbf
• Outer Ring Width: 15 mm
• Material: Steel
• Bearing Design: Non-Expansion
• I.D.: 1.000 in
• Static Load Rating [Max]: 1560 lbf
• Inch/Metric: Inch Bore
• Rolling Element: Ball Bearing
• Static Capacity: 1560 lbf
• Weight: 0.4 LB
• EAN or UPC: 87796054769
