Fafnir 5207WD Angular Contact Ball Bearing Light Duty Series 5200

Product Description

The Fafnir 5207WD Angular Contact Ball Bearing is engineered for combination radial and axial loading. This light duty bearing has a bore diameter of thirty-five millimeters and an outer diameter of seventy-two millimeters. It is designed to handle higher axial loads and is suitable for various applications in agriculture and general industry.

• Designed for both radial and axial loads.
• Features a single shield closure for protection.
• Capable of supporting dynamic loads up to ten thousand five hundred pounds.

Product Highlights

This product is ideal for high-speed applications with a temperature rating of minus fifty to one hundred twenty degrees Celsius.

Product Information

Standard Information

• Brand: Fafnir
• MPN: 5207WD

Technical Specifications

• Bore Diameter: 35 mm
• Outside Diameter: 72 mm
• Width: 27 mm
• Contact Angle: 30 degrees
• Number of Rows: 2
• Load Capacity: 10500 lb Dynamic / 8300 lb Static
• Maximum Speed: 5610 rpm
• Material: Steel
• Temperature Rating: -50 to 120 degrees Celsius
• Finish: Uncoated
• Closure Type: Single Shield
