Esab 255013112 Stick Electrode - Atom Arc 7018 Welding Wires, 3/16 Dia., 14 Long, 50 lb Can

Product Description

The Esab 255013112 Stick Electrode, also known as Atom Arc 7018, offers optimal welding performance. This electrode, with a 3/16 inch diameter and 14 inch length, is designed for carbon steel and low-alloy steel applications.

• Premium quality electrode
• Wide range of welding parameters
• Reduced post weld clean up

Product Highlights

This welding electrode is well-suited for various welding positions including flat, horizontal, overhead, vertical-down, and vertical-up. It offers reduced post-weld clean-up, delivering cleaner welds with minimal effort.

Product Information

Standard Information

• Brand: Esab
• MPN: 255013112
• UPC: 662303016135
• Country of Origin: US
• Weight: 50 lb

Technical Specifications

• Classification: Tig Tungsten Electrodes
• Category: Welding Supplies, Tig Welding, Tig Torch Parts & Accessories
• Material: Carbon Steel
• Diameter: 3/16 in
• Length: 14 in
• Packing Type: Hermetically Sealed Can
• Tensile Strength (As Welded): 78 ksi
• Tensile Strength (Minimum Required): 70 ksi
• Yield Strength (As Welded): 68 ksi
• Yield Strength (Minimum Required): 57 ksi
• Elongation (As Welded): 33%
• Elongation (Minimum Required): 30%
• Welding Current Designation: AC, DCEP
• Welding Positions: Flat, Horizontal, Overhead, Vertical-Down, Vertical-Up
• For Welding Material Types: Carbon Steel to Carbon Steel, Carbon Steel to Low-Alloy Steel, Low-Alloy Steel to Low-Alloy Steel
