Esab 0445-100921 Tig Stick Welding System 300A

Product Description

The ESAB 0445-100921 is a portable TIG and Stick welding power supply built for demanding field and shop applications. Weighing 33 pounds, the Renegade ET 300iP delivers 300 amps at 40 percent duty cycle while maintaining a compact, rugged form factor suited for extreme environments. The unit automatically accepts single- and three-phase input power from 208 volts to 460 volts, requiring no manual switching. Output range spans 5 to 300 amps, providing flexibility across a wide range of TIG and Stick welding tasks. Licensed welders and skilled trade professionals working in industrial, construction, and maintenance environments are the primary installers and operators of this system.

The Renegade ET 300iP is designed for both in-shop use and remote jobsite deployment. Its three-handle design allows easy transport through manholes and other restricted-access areas. The pulse HF TIG function covers a frequency range of 0.1 to 1000 Hz, supporting precise arc control, improved penetration, and faster travel speeds. The package ships with a 10-foot input cable, a shoulder strap, and two male 50mm OKC connectors. Air-cooled and water-cooled torch packages are available separately for different process requirements.

Key Features

• 300 amps output at 40 percent duty cycle with a 33-pound unit weight, highest power-to-weight ratio in its class
• Automatic single- and three-phase input acceptance from 208V to 460V with no manual reconfiguration
• Pulse HF TIG with 0.1 to 1000 Hz frequency range for precise arc control and improved penetration
• Three-handle design for field transport through confined spaces including manholes
• Digital readout display with large tactile buttons for easy parameter setting and remote readability
• Compatible with air-cooled and water-cooled torch packages for process flexibility

Compatibility

Designed as an OEM-style replacement and direct-fit unit for ESAB Renegade ET 300iP TIG and Stick welding system applications. Accepts standard 50mm OKC connector torch and accessory configurations.

Installation Notes

Installation and operation should be performed by a qualified welding technician or licensed electrician familiar with NFPA 70 (NEC) requirements for welding equipment. Disconnect and lock out all input power before making any electrical connections. Verify input voltage and phase configuration match the supply circuit before connecting the input cable. Inspect all connectors and the input cable for damage before each use.

Technical Specifications

• Output Amperage Range: 5 to 300 amps
• Duty Cycle: 40 percent at 300 amps
• Input Voltage: 208 to 460 volts
• Input Phase: Single-phase and three-phase (automatic)
• Pulse TIG Frequency Range: 0.1 to 1000 Hz
• Unit Weight: 33 pounds
• Package Weight: 37 pounds
• Input Cable Length: 10 feet
• Included Connectors: Two male 50mm OKC connectors
• UOM: Each
• UPC: 7322376229759

Standard Information

• Brand: ESAB
• Manufacturer Part Number: 0445-100921
