Erie VT2317G13A030 Controls Part Number 24v 3/4 Sweat 2-Way N.C. Zone Valve

Product Description

The Erie VT2317G13A030 is a 24-volt, 3/4-inch sweat 2-way normally closed zone valve designed to manage the flow of hot or cold water in hydronic heating or cooling systems. This valve features a 7.0 Cv flow capacity and 36-inch wire leads, making it suitable for commercial and industrial applications.

• 24-volt operation
• 3/4-inch sweat connection
• 2-way design, normally closed

Product Highlights

Erie VT2317G13A030 is ideal for controlling water flow in various heating and cooling systems. The valve's 7.0 Cv capacity ensures reliable performance in medium to large zones.

Product Information

Standard Information

• Brand: Erie
• Type: PopTop Forged 2-Way General Zone Valve Body 3/4 Sweat
• Pipe Size: 3/4 inches

Technical Specifications

• Voltage: 24 volts
• Flow Capacity: 7.0 Cv
• Connection Type: Sweat
• Wire Leads: 36 inches
• Normally Closed: Yes
• Item Weight: 1.6 pounds
• Dimensions: 5 x 4.5 x 3 inches
