ERICO TDS1301TR150 Transient Discriminating Surge Diverter 20 kA Three Mode 120-150 VAC

Product Description

The ERICO TDS1301TR150 is a transient discriminating surge diverter designed to protect electrical systems. It operates within a voltage range of one hundred twenty to one hundred fifty volts AC. This surge diverter is effective for both commercial and residential applications.

• 20 kA surge rating for effective protection
• Compact DIN rail mounting
• Mechanical flag indicator for status monitoring

Product Highlights

This device is ideal for solar power installations, telecom systems, and utility applications.

Product Information

Standard Information

• Manufacturer: ERICO INC
• UPC: 782856621751

Technical Specifications

• Type: Transient Discriminating
• Class: III
• Dimensions: Three point five four inches H x zero point seven one inches W x two point six eight inches D
• Electrical Ratings: One hundred twenty to one hundred fifty VAC
• Enclosure Type: IP20/NEMA 1
• Environmental Conditions: Negative forty to one hundred seventy-six degrees Fahrenheit
• Frequency Rating: Zero to one hundred Hz
• Indicator Type: Mechanical Flag
• Material: Thermoplastic
• Modes of Protection: Three/L-N/L-PE/N-PE
• Mounting Type: DIN Rail
• Nominal Discharge Current: Eight kA
• Response Time: Five ns
• Short Circuit Current Rating: Two hundred kA
• Terminal Type: Line/Neutral/PE
