Erico TAC3D2Q Cable to Cable, TA, 350 kcmil Concentric, 0.681 inches Conductor 1 OD, 4/0 Concentric, 0.528 inches Conductor 2 OD

Product Description

The ERICO TAC3D2Q cable to cable Cadweld graphite mold is designed for various connection styles and conductor combinations. This TA mold connects a 350 kcmil concentric conductor with a 0.681" outer diameter to a 4/0 concentric conductor with a 0.528" outer diameter.

• Forms a permanent, low resistance connection
• Provides a molecular bond
• nVent ERICO Cadweld Exothermic Connections are rated with the same current capacity as the conductor

Product Highlights

The TAC3D2Q mold offers a reliable and visually inspectable connection, utilizing portable installation equipment without needing an external power source.

Product Information

Standard Information

• Brand: ERICO
• Manufacturer Part Number: TAC3D2Q
• Country of Origin: US - United States

Technical Specifications

• Mold Family: TA
• Conductor 1: 350 kcmil Concentric
• Conductor 1 Outer Diameter, Nominal: 0.68"
• Conductor 2: 4/0 Concentric
• Conductor 2 Outer Diameter, Nominal: 0.53"
• Mold Split: Horizontal
• Split Crucible: No
• Wear Plates: No
• Mold Only: No
• Welding Material: 150 or 150PLUSF20, Sold Separately
• Handle Clamp: L160, Sold Separately
• Price Key: C
• Ease of Use: Preferred
• UPC: 782856554042
• EAN: 0782856554042
• Standard Packaging Quantity: 1
• Packing Quantity: 1
• Manufacturer: nVent
• Manufacturer Part No: TAC3D2Q
• ECCN: EAR99
• UNSPSC: 39121457
• Application: Connects Cable to Cable
