Product Description
The Erico TAC1T1T Type TA Standard Weld Metal Mold is designed for use with a two American Wire Gauge conductor configuration. This mold allows for the creation of permanent exothermic connections, giving you a reliable bond between cables. Suitable for various applications, this mold is constructed from durable graphite material and can handle different connection styles.
- Designed for up to 2 AWG conductors
- Portable and requires no external power source
- UL and cULus listed for safety
Product Highlights
Efficient for creating low resistance connections, the TAC1T1T mold is ideal for electrical bonding and grounding projects.
Product Information
Standard Information
-
Brand: Erico
-
Type: Type TA Standard
Technical Specifications
-
Conductor Size: 2 AWG
-
Connection Type: Cable to Cable
-
Country of Origin: US
-
Handle Clamp: L160
-
Material: Graphite
-
Mfg Standards/Approvals: UL, cULus Listed
-
Mold Price Key: C
-
Mold Size: 3 inches wide
-
Package Height: 233.68 mm
-
Package Length: 96.52 mm
-
Package Weight: 1.38 kg
-
Package Width: 93.98 mm
