Erico GT1182G nVent ERICO CADWELD ONE-SHOT GT Single Use Weld Metal Mold, 2/0 AWG Stranded Conductor

Product Description

The Erico GT1182G is a single use weld metal mold designed for 2/0 AWG stranded conductors. This ceramic mold replaces the need for graphite molds and handle clamps. It produces a permanent connection that resists loosening and corrosion.

• Single use ceramic mold
• Creates a durable connection
• Compatible with multiple rod types

Product Highlights

Use the Erico GT1182G for reliable electrical connections in various applications.

Product Information

Standard Information

• Brand: Erico
• MPN: GT1182G

Technical Specifications

• Application: Facility electrical protection, lightning protection, rail, solar power, telecom, utility and wind power applications
• Conductor Size: 2/0 AWG stranded
• Connection Type: Cable to ground rod
• Country of Origin: US
• Material: Ceramic
• Mfg Standards/Approvals: ARRA Compliant, Buy American Act Compliant, cULus Listed, NEC Certified
• Package Height: 1.8821 inches
• Package Length: 1.7967 inches
• Package Weight: 0.5004 lb
• Package Width: 4.1605 inches
• Rod Size: 3/4 inches
• Specifications: Traditional welding material type
• Type: Type GT Single Use
