EPC 10033584 102 Solder Tube Union, 1 in, C x C, Copper, Domestic

Product Description

The EPC 10033584 is a solder tube union designed for joining copper pipes. This fitting is classified as a union and features a nominal size of one inch in a copper material. It is compliant with ASME/ANSI B16.22 and MSS SP104 standards, suitable for both industrial and residential applications.

• Built from high-quality copper, ensuring durability and reliability.
• Pressure rated up to four hundred ninety psi.
• Temperature range of negative twenty to one hundred degrees Fahrenheit.

Product Highlights

This solder joint fitting is designed for easy installation and is ideal for applications requiring robust pipe connections.

Product Information

Standard Information

• Manufacturer: EPC
• Part Number: 10033584

Technical Specifications

• Application: Industrial and Residential
• Domestic/Import: Domestic
• End Style: C x C
• Fitting Type: Union
• Material: Copper
• Nominal Size: 1 in
• Pressure Rating: 490 psi
• Temperature Rating: -20 to 100 deg F
• Series: 102
• Standards/Approvals: ASME/ANSI B16.22 | MSS SP104
