Engineered Source 14050 Gate Valve

Product Description

The Engineered Source 14050 is a gate valve suitable for high vacuum applications. The construction includes a durable stainless steel body and a pneumatic actuator with a position indicator. This valve is designed to effectively maintain pressure and allow for smooth flow conductance.

• Stainless steel body construction
• Pneumatic actuator with position indicator
• Compatible with high vacuum environments

Product Highlights

This valve is engineered for reliability in demanding environments, making it a trusted choice for professionals.

Product Information

Standard Information

• Manufacturer: VAT
• Series: 14.0

Technical Specifications

• Model: 140
• Inside Diameter: 320 (12)
• Flange: JIS (compatible with JIS B 2290)
• Body Material: Stainless steel
• Actuator: Pneumatic actuator with position indicator without solenoid valve double acting
• Solenoid Kit Included: Yes
• Minimum Pressure: 1.00 x 10-10 mbar
• Maximum Pressure: 1.2 bar (abs)
• Molecular Flow Conductance: 30000.0 ls-1
• Weight: 246.92 kg
• Valve Seal Material: Fluorocarbon (FKM)
• Voltage: ≤ 250VAC
• Cycle Life: 200,000
• Helium Leak Rate: 1.00 x 10-9 mbar*L/s
