Enerpac RWH202 Hollow Plunger Hydraulic Cylinder 23500 lbs Capacity, 2.02 in Stroke

Product Description

The ENERPAC RWH202 2" Holl-O-Cylinder is a powerful tool for hydraulic projects. Made from high-grade materials, the cylinder delivers superior performance. Hollow-plunger cylinders support loads from both ends, allowing for push and pull operations. Single-acting cylinders are spring-loaded to ease unloading.

• Hollow-plunger design for push and pull operations
• Threaded collar for mounting options
• Base mounting holes for T-slot, tabletop, and surface mounting

Product Highlights

The ENERPAC RWH202 cylinder's robust design allows for maximum pushing power. Threaded collars and base mounting holes allow mounting flexibility.

Product Information

Standard Information

• Brand: ENERPAC
• Manufacturer Part Number: RWH202
• Country of Origin: China

Technical Specifications

• Single Acting/Double Acting: Single Acting
• Cylinder Type: Hollow Plunger
• Body Material: Steel
• Nominal Capacity: 23,500 lb
• Max. Push Capacity: 23,500 lb
• Stroke Length: 2.02 in
• Nominal Stroke Length: 2 in
• Effective Push Area: 4.74 sq in
• Max. Pressure: 5,000 psi
• Oil Capacity Push: 9.48 cu in
• Retracted Height: 6.37 in
• Extended Height: 8.39 in
• Outside Dia.: 3.87 in
• Plunger Dia.: 2.12 in
• Plunger Thread Size: 1.06"
• Collar Thread Size: 3/8"-18
• Base Bolt Circle Dia.: 3.25 in
• Base Mounting Thread Size: 3/8"-16
• Center Hole Diameter: 1.06 in
• Model: RWH-202
• Brand: Enerpac
• SKU: RWH202
• Cylinder effective area advance (in2): 4.74
• Cylinder material: Steel
• Max cylinder capacity advance (lbs): 23,500
• Max operating pressure (psi): 5,000
• Oil capacity advance (in3): 9.48
• Plunger type: Hollow
• Return type: Single-acting, spring return
• Stroke (in): 2.02
• Series: RWH
• Product Line: Workholding Tools
• Brand Manufacturer: Enerpac
• MPN: RWH202
• Manufacturer: Enerpac
• Prop 65: No
