Enerpac RC256 25.8 ton Capacity 6.25 inch Stroke General Purpose Hydraulic Cylinder

Product Description

The Enerpac RC256 General Purpose Hydraulic Cylinder is designed for single-acting use with a 25.8 ton capacity and a 6.25 inch stroke. It is well-suited for various hydraulic applications.

• Single-acting hydraulic cylinder
• 25.8 ton nominal capacity
• 6.25 inch stroke length

Product Highlights

This hydraulic cylinder offers a robust 25.8 ton push capacity and a steel construction for durable use. It features a 6.25 inch stroke for versatile functionality in various hydraulics tasks.

Product Information

Standard Information

• Name: Enerpac RC256
• Type: General Purpose Hydraulic Cylinder

Technical Specifications

• Nominal Capacity: 25 ton
• Max Push Capacity: 25 ton
• Stroke Length: 6.25 in
• Effective Push Area: 5.16 sq in
• Max Pressure: 10,000 psi
• Oil Capacity Push: 32.23 cu in
• Retracted Height: 10.75 in
• Extended Height: 17 in
• Outside Diameter: 3.38 in
• Plunger Diameter: 2.25 in
• Plunger Thread Size: 1-1/2-16
• Collar Thread Size: 3-5/16-12
• Base Bolt Circle Diameter: 2.31 in
• Center Hole Diameter: 2 1/4 in
