Enerpac RC-59 Cylinder 5 Tons 9-1/8in Stroke

Product Description

The Enerpac RC-59 is a single-acting hydraulic cylinder designed for reliability in heavy-duty applications. With a lift capacity of five tons and a stroke length of nine and one-eighth inches, this cylinder meets the demands of lifting and pushing tasks. Ideal for use in construction, automotive repair, and industrial applications, it is constructed with steel for durability.

• 5 ton capacity
• 9 1/8 inch stroke length
• Maximum pressure of 10,000 psi

Product Highlights

This hydraulic cylinder is suitable for various general-purpose applications and includes important accessories like a coupler and dust cap.

Product Information

Standard Information

• Manufacturer: Enerpac
• MPN: RC-59

Technical Specifications

• Item: Hydraulic Ram
• Type: General Purpose
• Handle: Yes
• Series: RC
• Includes: Coupler, Dust Cap
• Thread Size: 1/4-20
• Oil Capacity: 9.07 cu in
• Outside Diameter: 1.5 in
• Plunger Diameter: 1 in
• Body Material: Steel
• Cylinder Type: General Purpose
• Max Pressure: 10,000 psi
• Stroke Length: 9 1/8 in
• Effective Area: 1.00 sq in
• Extended Height: 21.33 in
• Weight Capacity: 5 tons
• Bolt Circle Diameter: 1 in
• Center Hole Diameter: 1 in
• Nominal Capacity: 5 ton
• Retracted Height: 12.75 in
• Oil Capacity Push: 9.07 cu in
• Collar Thread Size: 1-1/2-16
• Max Push Capacity: 5 ton
• Effective Push Area: 0.99 sq in
• Plunger Thread Size: 3/4-16
• Base Bolt Circle Diameter: 1 in
• Nominal Stroke Length: 9 in
• Single Acting: Yes
• Country of Origin: China
