Enerpac FA9TESTD Hydraulic Flange Alignment Tool

Product Description

The ENERPAC FA9TESTD is a hydraulic-powered flange alignment tool designed for use in pipe and flange assembly operations across industrial and commercial applications. It delivers controlled hydraulic force to bring misaligned pipe flanges into proper position for bolting, eliminating the need for manual prying or improvised rigging. Weighing 58.5 pounds, the unit is built for job-site durability. Its dimensions of 20.51 inches in length, 3.94 inches in width, and 10.51 inches in height make it suited for use in tight piping corridors and congested mechanical rooms where space is limited.

This tool is used in piping systems where flanged connections require precise alignment before gasket installation and bolting. Typical applications include industrial plant maintenance, process piping fabrication, and heavy mechanical construction. It is most commonly deployed by pipefitters, millwrights, and industrial maintenance technicians working on flanged connections in steel, cast iron, or other rigid piping systems. The hydraulic power source allows for consistent, repeatable force application that manual tools cannot reliably provide.

Key Features

• Hydraulic power source delivers controlled, consistent alignment force without manual prying
• Compact form factor at 20.51 inches long and 3.94 inches wide for use in confined spaces
• Robust construction at 58.5 pounds, built for sustained job-site use
• Single-unit package with a minimum order quantity of one

Compatibility

Designed as a hydraulic flange alignment tool for use in industrial and commercial pipe flange assembly and maintenance operations.

Installation Notes

Installation and operation of hydraulic flange alignment tools should be performed by qualified pipefitters or millwrights familiar with hydraulic tooling and flanged piping systems. Isolate and depressurize the piping system fully before beginning alignment work. Follow applicable codes including ASME B31.3 for process piping or the relevant installation standard for the system being serviced. Inspect hydraulic hoses and couplings for integrity before each use and never exceed the rated hydraulic pressure of the tool.
