ENERCO F102600 100,000 BTU Universal Tube Heater Burner

Product Description

The ENERCO F102600 is a universal burner designed for tube heaters, providing a heating capacity of 100,000 BTU. This two-stage burner is suitable for various manufacturers' tube heaters, provided compatibility with BTU ratings and gas types. It connects easily to four-inch outer diameter steel tubing and features a sealed control box along with hot surface ignition.

• Compatible with both natural gas and propane.
• Two-stage design with efficient ignition.
• Sealed control box for enhanced safety.

Product Highlights

This burner is ideal for applications requiring a reliable heat source. Its design supports a range of mounting heights, allowing flexibility in installation.

Product Information

Standard Information

• Brand: ENERCO
• MPN: F102600

Technical Specifications

• BTU: 100,000
• Fuel Type: Natural Gas or Propane
• Gas Inlet Connection: 1/2 inch ID FPT
• Electrical Rating: 120V
• Electrical Connection: Pigtail Leads in Junction Box
• Mounting Height Range: 12 feet - 15 feet
• Clearance to Combustibles: Horizontal: Above 6 inches; Below 74 inches; Sides: 36 inches
• Venting Length Min/Max: 25 feet
• Venting Exhaust: 30 feet
• Venting Air Intake: 30 feet
• Thermostat: Optional
• Ignition: Hot Surface
• Certification: CSA
• Tube Size: 4 inches O.D.
• Weight: 36 lbs
