Encore Wire 118101701450 Copper THHN 1 Stranded 1 AWG 1000 ft

Product Description

The Encore Wire 118101701450 is a type THWN-2 building wire with a stranded copper conductor. This wire is rated for 600 VAC and 145 A. It features a PVC insulation and a nylon jacket, with an outside diameter of 0.435 inches. Suitable for commercial applications, this 1 AWG conductor has 19 strands and a 1000 ft length.

• Color code polyvinyl chloride (PVC), heat and moisture resistant, flame retardant compound
• Stranded, uncoated bare copper per ASTM-B3, ASTM-B8 and ASTM-B787
• A tough, polyamide, nylon outer covering per UL-83 and UL-1063

Product Highlights

Type THWN-2 building wire with a stranded copper conductor, PVC insulation, and nylon jacket.

Product Information

Standard Information

• Brand: Encore Wire
• Manufacturer Part Number: 118101701450
• Country of Origin: USA

Technical Specifications

• Amperage Rating: 145 A
• Conductor Size: 1 AWG
• Conductor Type: Stranded Copper
• Insulation Material: PVC
• Jacket Color: Black
• Jacket Material: Nylon
• Length: 1000 ft
• Number of Conductors: 1
• Outside Diameter: 0.435 in
• Packaging Type: Reel
• Strands: 19
• Temperature Rating: 90 deg C
• Type: Type THWN-2
• Voltage Rating: 600 VAC
