Encore Wire 105100803065 Thhn Wire 12 Awg Solid 600V 2500 Ft Red

Product Description

The ENCORE WIRE 105100803065 is a Type THHN building wire designed for general-purpose electrical wiring in residential, commercial, and industrial applications. It features a solid copper conductor in 12 AWG gauge, rated at 600 volts AC and 30 amps, with a PVC insulation layer and a nylon jacket. The outer diameter measures 0.128 inches. The red jacket aids in circuit identification per NEC color-coding conventions. This wire ships on a reel in a 2500 ft length, making it suitable for larger rough-in wiring jobs where minimizing splices is a priority. Licensed electricians are the primary installers of this product.

Type THHN wire is a standard choice for branch circuit wiring in conduit runs, including EMT, rigid metal conduit, and PVC conduit systems. The 12 AWG solid conductor is commonly used for 20-amp branch circuits in residential wiring, lighting circuits, and general-purpose outlet circuits. The nylon jacket provides abrasion resistance during pull-through installations, and the 90 degrees C dry rating supports use in higher-temperature environments such as attic runs or equipment rooms. The 2500 ft reel format suits large residential builds, multi-unit projects, or commercial rough-in work.

Key Features

• Type THHN rated at 600 volts AC and 30 amps
• 12 AWG solid copper conductor for reliable conductivity and easy termination
• PVC insulation with nylon jacket for abrasion and moisture resistance in conduit
• 90 degrees C temperature rating for dry and damp locations
• Red jacket for circuit identification per NEC conventions
• 2500 ft reel packaging reduces splice points on large wiring jobs

Compatibility

Designed as a standard Type THHN building wire suitable for use in conduit systems where 12 AWG, 600-volt-rated solid copper conductors are specified.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the circuit before making any connections. This wire is rated for use in conduit and is not approved for direct burial or exposed aerial runs unless the application is otherwise code-compliant. Avoid sharp bends or kinks during pull-through to maintain insulation integrity.

Technical Specifications

• Wire Type: THHN
• Conductor Material: Solid Copper
• Conductor Size: 12 AWG
• Voltage Rating: 600 volts AC
• Ampacity: 30 amps
• Number of Conductors: 1
• Outer Diameter: 0.128 inches
• Length: 2500 ft
• Insulation Material: PVC
• Jacket Material: Nylon
• Jacket Color: Red
• Temperature Rating: 90 degrees C
• Packaging: Reel

Standard Information

• Brand: ENCORE WIRE
• Manufacturer Part Number: 105100803065
