EMS Industries PBT-500 ILSCO AL MECH 500MCM-4 INS W UL

Product Description

EMS Industries PBT-500 is a dual-rated insulated splicer/reducer connector. It is designed for aluminum and copper conductors and can handle up to 600 VAC. This connector works well with wire sizes ranging from four AWG to five hundred kcmil. It offers a reliable connection with a maximum current carrying capacity of 430 A. The temperature rating of this product ranges from negative forty-five degrees to ninety degrees Celsius.

• Two-port and two-wire design.
• High dielectric strength with chemical resistance.
• Removable port and screw plugs.

Product Highlights

This connector ensures reliability and flexibility for various electrical applications.

Product Information

Standard Information

• Brand: EMS Industries
• MPN: PBT-500

Technical Specifications

• Conductor Type: Aluminum/Copper
• Dimensions: 5.38 inches L x 1.437 inches W x 3.03 inches H
• Material: Aluminum
• Specifications: 4 AWG to 500 kcmil wire, 3/8 inches hex, 430 A
• Voltage Rating: 600 VAC
• Temperature Rating: -45 to 90 degrees Celsius
• Standards/Approvals: CSA File No. LR-29601, UL 486A/486B, UL 453G, UL File No. E6207, PROP65: Cancer and Reproductive Harm - www.P65warnings.ca.gov
• Type: Type PBT 2-Port 2-Wire Dual Rated Insulated
