Emerson ZR32K5E-PFV-800 Compressor, 208-230/1/60

Product Description

The EMERSON ZR32K5E-PFV-800 compressor is designed for HVAC applications and uses R407C refrigerant. This 208-230 VAC, 1-phase compressor features a scroll design for quiet and reliable operation. It has a capacity of 32000 BTU/hr and a power rating of 2990 W. The compressor includes internal pressure protection and improved temperature protection.

• Optimized scroll and seal design for quiet, reliable operation
• High-efficiency motor with improved temperature protection
• Suitable for air conditioning applications

Product Highlights

This compressor is ideal for HVAC systems requiring R407C refrigerant and 208-230V, 1-phase power.

Product Information

Standard Information

• Brand: EMERSON
• Manufacturer Part Number: ZR32K5E-PFV-800

Technical Specifications

• Phase: 1-phase
• Height: 15.86"
• Length: 9.50"
• Frequency: 60Hz
• Dimensions: 9.50" x 9.50" x 15.86"
• Application: HVAC
• Refrigerant: R407C
• Series: ZR
• Liquid Line Size: 1/2"
• BTU Rating: 32000 Btu/hr
• Tonnage: 2.5 ton
• Amperage Rating: 13.1 A
• Voltage Rating: 208 to 230 VAC
• Compressor Oil: POE-AK/DA, 3MA/SP32
• Discharge Line Size: 1/2 in Stub
• Suction Line Size: 3/4 in Stub
• Power Rating: 2990 W, 2-1/2 hp
• Speed Rating: 3500 rpm
• Sound Level: 68 to 73 dBA
• EER Rating: 10.5 to 21.3
