Emerson TC-515 APP 1-1/2 DC EMT S-SCR Coupling

Product Description

The Emerson TC-515 APP 1-1/2' DC EMT S-SCR Coupling is designed for use with EMT conduit. This straight set-screw coupling is part of the TC-500 series and is made from die-cast zinc. It connects lengths of steel EMT in both dry and damp locations.

• Die cast zinc construction for durability
• Pre-set set screws for secure connections
• Designed for 1-1/2 inch EMT conduit

Product Highlights

This coupling allows for effective joining of EMT lengths, ensuring a solid connection in varied environments.

Product Information

Standard Information

• Manufacturer: Emerson Electric
• UPC: 68785510515

Technical Specifications

• Application: To join lengths of steel EMT for concretetight, dry or damp locations
• Color: Metallic
• Dimensions: 2.2 in OD x 2.87 in L
• Manufacturer Part Number: TC-515
• Material: Die Cast Zinc
• Series: TC-500
• Size: 1-1/2 in
• Standards/Approvals: UL 514B File No. E35001|CSA 208044|CSA C22.2 No. 18.3|NEMA FB-1
• Suitable For Use With: EMT Conduit
• Type: Straight
