Emerson TC-511 APP 1/2 DC EMT S-SCR CPLG

Product Description

The Emerson TC-511 APP 1/2 DC EMT S-SCR CPLG is a set screw coupling designed for use with EMT conduit. This coupling is part of the TC-500 series and is made of die cast zinc. It is ideal for connecting lengths of steel EMT for applications in dry, damp, or concretetight locations.

• Manufactured from die cast zinc
• Suitable for EMT conduit connections
• Dimensions include an outer diameter of 1.05 inches and a length of 1.5 inches

Product Highlights

The coupling features pre-set set screws that enhance the connection strength and stability.

Product Information

Standard Information

• Manufacturer: Emerson Electric
• UPC: 68785510511

Technical Specifications

• Application: To join lengths of steel EMT for concretetight, dry, or damp locations
• Color: Metallic
• Dimensions: 1.05 in OD x 1.5 in L
• MPN: TC-511
• Material: Die Cast Zinc
• Series: TC-500
• Size: 1/2 in
• Standards/Approvals: UL 514B File No. E35001 | CSA 208044 | CSA C22.2 No. 18.3 | NEMA FB-1
• Suitable For Use With: EMT Conduit
• Type: Straight
