Emerson C100-M Appleton UNILETS Conduit Outlet Body 1 in Hub Form 35

Product Description

The Emerson C100-M Appleton UNILETS Conduit Outlet Body is designed for efficient conduit systems. It features a type-C body with a one-inch hub suitable for rigid steel or aluminum conduit. This product has a capacity of twelve point five cubic inches and measures seven point thirteen inches in length, one point eighty-one inches in width, and one point ninety-four inches in height.

• Smooth, rounded bushing protects conductor insulation
• Accurately tapped threads for secure connections
• Form 35 malleable iron construction

Product Highlights

This outlet body allows for the connection and change of direction in conduit runs. It facilitates the installation of branch runs and provides access to conductors for maintenance tasks.

Product Information

Standard Information

• Manufacturer: Emerson Electric
• UPC: 78138116485

Technical Specifications

• Application: For Rigid Steel/Aluminum and IMC Conduit
• Connection Type: Tapered FNPT
• Dimensions: 7.13 in L x 1.81 in W x 1.94 in H
• Enclosure: NEMA FB-1
• Finish: Triple Coated
• Hub Size: 1 in
• Material: Malleable Iron
• Mounting Type: Surface
• Number of Hubs: 2
• Standards/Approvals: ARRA Compliant | UL 514B File No. E2527 | C22.2 No. 18.3/065183 Certified
• Type: Type-C
