Emerson B-75 B-75 GEDNEY INS BUSH 3/4 in Trade

Product Description

The Emerson B-75 is a Type B Conduit Bushing designed for use in electrical applications. It measures three-fourths of an inch in trade size and is made of steel with a zinc plated finish. This bushing serves as an effective means to protect insulated conductors from abrasion during conduit installation.

• Type B insulated design to enhance safety
• Compatible with threaded rigid conduit and IMC
• Temperature rating of three hundred two degrees Fahrenheit

Product Highlights

This conduit bushing is essential for providing proper support and protection for insulated conductors at conduit entry and exit points.

Product Information

Standard Information

• Manufacturer: Emerson Electric
• UPC: 78312602903

Technical Specifications

• Application: For threaded rigid conduit and IMC
• Dimensions: 1-3/8 inches OD x 5/8 inches W
• Finish: Zinc Plated
• Insulated Non Insulated: Insulated
• Manufacturer Part Number: B-75
• Material: Steel
• Standards/Approvals: CSA 011584 C22.2 No.18, Federal Specification W-F-408E, NEMA FB-1, UL 514B, UL File No. E11853
• Temperature Rating: 302 degrees Fahrenheit
• Trade Size: 3/4 inches
• Type: Type B
